NVIDIA Quadro RTX 6000 (Laptop)

NVIDIA Quadro RTX 6000 (Laptop)

De Nvidia Quadro RTX 6000 voor laptops is een professionele high-end grafische kaart voor grote en krachtige laptops en mobile workstations. De GPU is gebaseerd op dezelfde TU106-chip als de GeForce RTX 2080 Ti voor consumenten, maar biedt lagere kloksnelheden.

De Quadro-GPU's beschikken over gecertificeerde drivers die geoptimaliseerd zijn voor stabiliteit en prestaties in professionele applicaties (CAD, DCC, medische applicaties, visualisatie-applicaties). De prestaties zijn op dit vlak dus veel beter dan die van overeenkomstige consumenten-GPU's.

Nvidia fabriceert de Turing TU102-chip op een 12-nm FinFET-proces en implementeert features zoals Deep Learning Super Sampling (DLSS) en Real-Time Ray-Tracing (RTRT), wat zou moeten leiden tot meer realistische lichteffecten dan met oudere GPU's gebaseerd op Nvidia's Pascal-architectuur (als games dit ondersteunen). De Quadro RTX 5000 biedt ondersteuning voor DisplayPort 1.4, HDMI 2.0b, HDR, Simultaneous Multi-Projection (SMP) en video en-/decoderen van H.265 (PlayReady 3.0).

Door de lagere kloksnelheden is de mobile RTX 6000 iets trager dan de desktop-versie met dezelfde naam. Volgens Nvidia is een desktopsysteem met RTX 6000 zo'n 13% sneller in de SpecViewPerf13 4k-benchmark.

Omwille van het extreem hoge energieverbruik van 200 Watt (TDP) heeft de Quadro RTX 6000 voor laptops een uitstekende koeling nodig en kan hij alleen toegepast worden in grote laptops.

Quadro Turing Serie

Quadro RTX 6000 (Laptop) 4608 @ 1.28 - 1.46 GHz384 bit @ 14000 MHz
Quadro RTX 5000 (Laptop) 3072 @ 1.04 - 1.55 GHz256 bit @ 14000 MHz
Quadro RTX 5000 Max-Q 3072 @ 0.6 - 1.35 GHz256 bit @ 14000 MHz
Quadro RTX 4000 (Laptop) 2560 @ 1.11 - 1.56 GHz256 bit @ 14000 MHz
Quadro RTX 4000 Max-Q 2560 @ 0.78 - 1.38 GHz256 bit @ 14000 MHz
Quadro RTX 3000 (Laptop) 1920 @ 0.95 - 1.38 GHz192 bit @ 14000 MHz
Quadro RTX 3000 Max-Q 1920 @ 0.6 - 1.22 GHz192 bit @ 14000 MHz
Quadro T2000 (Laptop) 1024 @ 1.58 - 1.79 GHz128 bit @ 8000 MHz
Quadro T2000 Max-Q 1024 @ 0.93 - 1.5 GHz128 bit @ 8000 MHz
Quadro T1000 (Laptop) 768 @ 1.4 - 1.46 GHz128 bit @ 8000 MHz
T1000 896 @ 1.07 - 1.4 GHz128 bit @ 10000 MHz
T1200 Laptop GPU 1024 @ 0.86 - 1.43 GHz128 bit @ 10000 MHz
Quadro T1000 Max-Q 768 @ 0.8 - 1.46 GHz128 bit @ 8000 MHz
T600 Laptop GPU 896 @ 1.4 GHz128 bit @ 10000 MHz
T550 Laptop GPU 1024 @ 1.07 - 1.67 GHz64 bit @ 12000 MHz
T500 Laptop GPU 896 @ 1.37 - 1.7 GHz64 bit @ 10000 MHz
T600 640 @ 0.74 - 1.34 GHz128 bit @ 10000 MHz
CodenaamTU102
ArchitectuurTuring
Pipelines4608 - verenigd
Core-snelheid1275 - 1455 (Boost) MHz
Geheugensnelheid14000 MHz
Geheugenbusbreedte384 bit
GeheugentypeGDDR6
Max. hoeveelheid geheugen24 GB
Gedeeld geheugennee
APIDirectX 12_1, OpenGL 4.6
Stroomverbruik200 Watt
Aantal Transistoren18.6 Billion
technologie12 nm
FaciliteitenNVLink, DLSS, Raytraycing, VR Ready, G-SYNC, Vulkan, Multi Monitor
Laptop Groottegroot
Aangekondigde datum04.09.2019

Benchmarks

3DMark - 3DMark Time Spy Score
11084 Points (32%)
+ 1 Meer details   - Verberg vergelijkingstabel
SPECviewperf 13 specvp13 sw-04 +
SPECviewperf 13 - specvp13 sw-04
217 fps (58%)
+ 1 Meer details   - Verberg vergelijkingstabel
specvp13 3dsmax-06 +
SPECviewperf 13 - specvp13 3dsmax-06
217 fps (38%)
+ 1 Meer details   - Verberg vergelijkingstabel
- Benchmarkresultaten voor deze videokaart
red legend - Gemiddelde benchmarkresultaten voor deze videokaart
* Kleinere getallen betekenen een hogere prestatie

Voor meer games die mogelijk speelbaar zijn of voor een lijst van alle games en videokaarten, bezoek onze Gaming List
