Intel Pentium B970

Intel B970

De Intel Pentium B970 is een dual-core processor voor instapniveau notebooks. Deze is gebaseerd op de Sandy Bridge architectuur, maar vele eigenschappen zoals Turbo Boost voor de CPU, Hyper-Threading, AES, virtualisatie (VT-x en VT-d), Trusted Execution en Intel Quick Sync zijn gedeactiveerd. De Pentium B970 integreerd een grafische chip genaamd Intel HD Graphics die is gebaseerd op de HD Graphics 2000 met kloksnelheden van 650-1100 MHz (middels Turbo Boost).

De prestaties van de Pentium B970 zullen hoger moeten zijn dan gelijk geklokte Arrandale Pentium CPU's. De B970 zou dan ook ongeveer 10% beter moeten presteren dan een Pentium P6300.

De 35 watt TDP is inclusief geïntegreerde GPU en geheugencontroller.

SerieIntel Pentium
CodenaamSandy Bridge

Serie: Pentium Sandy Bridge

Intel Pentium B9802.4 GHz2 / 2 cores2 MB L3
Intel Pentium B970 « 2.3 GHz2 / 2 cores2 MB L3
Intel Pentium B9602.2 GHz2 / 2 cores2 MB L3
Intel Pentium B9502.1 GHz2 / 2 cores2 MB L3
Intel Pentium B9402 GHz2 / 2 cores2 MB L3
Intel Pentium 9971.6 GHz2 / 2 cores2 MB L3
Intel Pentium 9871.5 GHz2 / 2 cores2 MB L3
Intel Pentium 9771.4 GHz2 / 2 cores2 MB L3
Intel Pentium 9671.3 GHz2 / 2 cores2 MB L3
Intel Pentium 9571.2 GHz2 / 2 cores2 MB L3
Kloksnelheid2300 MHz
Level 1 Cache128 KB
Level 2 Cache512 KB
Level 3 Cache2 MB
Aantal Cores / Threads2 / 2
Stroomverbruik (TDP = Thermal Design Power)35 Watt
Aantal Transistoren624 miljoen
Productietechnologie32 nm
Chipgrootte149 mm2
Max. Temperatuur85 °C
SocketrPGA988B
FeaturesHD Graphics, DDR3 Memory Controller
GPUIntel HD Graphics (Sandy Bridge) (650 - 1150 MHz)
64-Bit64-Bit-ondersteuning
Architecturex86
Startprijs$125 U.S.
Aankondigingsdatum01-10-2011
Productlink (extern)ark.intel.com

Benchmarks

Cinebench R23 - Cinebench R23 Multi Core
792 Points (1%)
+ 1 Meer details   - Verberg vergelijkingstabel
AMD E1-2100
202 -74%
Intel Celeron N3350
328 -59%
Intel Celeron N2820
347 -56%
Intel Core 2 Duo SU7300
392 -51%
Intel Atom x7-Z8750
612 -23%
Intel Celeron N4020
616 -22%
AMD A4-5000
651 -18%
Intel Celeron N4500
709 -10%
Intel Celeron N6211
735 -7%
Intel Pentium B970
792
AMD A10-5745M
830 5%
Qualcomm Snapdragon 7c
830 5%
Intel Core i3-5010U
834 5%
AMD A6-5200
843 6%
Intel Pentium Silver N5030
911 15%
AMD 3020e
943 19%
AMD FX-7600P
949 20%
Intel Celeron N4100
961 21%
Intel Pentium Gold 4425Y
964 22%
...
AMD Ryzen 9 7945HX3D
32782 4039%
max:
AMD Ryzen Threadripper PRO 7995WX
107681 13496%
0%
100%
Cinebench R23 - Cinebench R23 Single Core
418 Points (18%)
+ 1 Meer details   - Verberg vergelijkingstabel
AMD A10-5745M
74.4 -82%
...
Intel Celeron N3350
252 -40%
Qualcomm Snapdragon 7c Gen 2
307 -27%
Intel Celeron N4020
308 -26%
Qualcomm Snapdragon 7c
321 -23%
Qualcomm Snapdragon 7c+ Gen 3
358 -14%
Intel Celeron N4100
386.5 -8%
Intel Pentium Gold 4425Y
388 -7%
Intel Core i3-5010U
411 -2%
Intel Celeron N4120
416.5 0%
Intel Pentium B970
418
Intel Celeron J4125
425.3 2%
Intel Pentium Silver N5030
430 3%
Intel Pentium Silver N5000
438 5%
Intel Celeron N6211
439 5%
Intel Celeron N4500
452 8%
AMD FX-7600P
481 15%
Intel Core i3-5005U
499 19%
Intel Core i3-N300
513 23%
Intel Pentium Gold 4415U
529 27%
...
Intel Core i7-13800H
2017 383%
max:
Intel Core Ultra 9 285K
2348 462%
0%
100%
Cinebench R20 - Cinebench R20 CPU (Single Core)
157.9 Points (18%)
+ 1 Meer details   + Toon vergelijkingstabel
Cinebench R20 - Cinebench R20 CPU (Multi Core)
305 Points (1%)
+ 1 Meer details   + Toon vergelijkingstabel
Cinebench R11.5 - Cinebench R11.5 CPU Multi 64 Bit
min: 1.66     gem: 1.7     mediaan: 1.8 (2%)     max: 1.78 Points
+ 3 Meer details   + Toon vergelijkingstabel
Cinebench R11.5 - Cinebench R11.5 CPU Single 64 Bit
0.8 Points (20%)
+ 1 Meer details   + Toon vergelijkingstabel
Cinebench R10 - Cinebench R10 Rend. Single (32bit)
min: 2881     gem: 2943     mediaan: 2954 (18%)     max: 2995 punten
+ 3 Meer details   + Toon vergelijkingstabel
Cinebench R10 - Cinebench R10 Rend. Multi (32bit)
min: 5665     gem: 5726     mediaan: 5697 (4%)     max: 5816 punten
+ 3 Meer details   + Toon vergelijkingstabel
Cinebench R10 - Cinebench R10 Rend. Multi (64bit)
min: 6721     gem: 6925     mediaan: 6989 (4%)     max: 7066 Points
+ 3 Meer details   + Toon vergelijkingstabel
Cinebench R10 - Cinebench R10 Rend. Single (64bit)
min: 3389     gem: 3589     mediaan: 3681 (4%)     max: 3696 Points
+ 3 Meer details   + Toon vergelijkingstabel
wPrime 2.10 - wPrime 2.0 1024m *
min: 1070     gem: 1254     mediaan: 1072 (13%)     max: 1621 s
+ 3 Meer details   + Toon vergelijkingstabel
wPrime 2.10 - wPrime 2.0 32m *
min: 34.61     gem: 39.6     mediaan: 35.8 (7%)     max: 48.33 s
+ 3 Meer details   + Toon vergelijkingstabel
7-Zip 18.03 - 7-Zip 18.03 Multi Thread 4 runs
4237 MIPS (2%)
+ 1 Meer details   + Toon vergelijkingstabel
7-Zip 18.03 - 7-Zip 18.03 Single Thread 4 runs
2446 MIPS (29%)
+ 1 Meer details   + Toon vergelijkingstabel
HWBOT x265 Benchmark v2.2 - HWBOT x265 4k Preset
1 fps (2%)
+ 1 Meer details   + Toon vergelijkingstabel
00.10.20.30.40.50.60.70.80.911.11.21.31.41.51.61.71.81.9Tooltip
Blender - Blender 2.79 BMW27 CPU *
12910 Seconds (91%)
+ 1 Meer details   + Toon vergelijkingstabel
R Benchmark 2.5 - R Benchmark 2.5 *
1.5 sec (32%)
+ 1 Meer details   + Toon vergelijkingstabel
3DMark 06 - CPU - 3DMark 06 - CPU
min: 2306     gem: 2321     mediaan: 2328 (5%)     max: 2329 Points
+ 3 Meer details   + Toon vergelijkingstabel
Super Pi mod 1.5 XS 1M - Super Pi mod 1.5 XS 1M *
min: 17.6     gem: 17.7     mediaan: 17.7 (4%)     max: 17.83 s
+ 3 Meer details   + Toon vergelijkingstabel
Super Pi mod 1.5 XS 2M - Super Pi mod 1.5 XS 2M *
min: 39.64     gem: 40.3     mediaan: 40.5 (2%)     max: 40.78 s
+ 3 Meer details   + Toon vergelijkingstabel
Super Pi Mod 1.5 XS 32M - Super Pi mod 1.5 XS 32M *
min: 894     gem: 904     mediaan: 904 (4%)     max: 913 s
+ 3 Meer details   + Toon vergelijkingstabel
SiSoft Sandra Dhrystone (MIPS) - SiSoft Sandra Dhrystone (MIPS)
min: 28100     gem: 28285     mediaan: 28285 (13%)     max: 28470 MIPS
+ 2 Meer details   + Toon vergelijkingstabel
SiSoft Sandra Whetstone (MFLOPS) - SiSoft Sandra Whetstone (MFLOPS)
min: 16500     gem: 16505     mediaan: 16505 (13%)     max: 16510 MFLOPS
+ 2 Meer details   + Toon vergelijkingstabel
Windows 7 Experience Index - Win7 CPU
6.2 Points (79%)
+ 2 Meer details   + Toon vergelijkingstabel
3DMark Vantage - 3DM Vant. Perf. CPU no Physx
min: 5141     gem: 5254     mediaan: 5242 (4%)     max: 5380 Points
+ 3 Meer details   + Toon vergelijkingstabel
3DMark 11 - 3DM11 Performance Physics
1989 Points (5%)
+ 1 Meer details   + Toon vergelijkingstabel
Geekbench 6.3 - Geekbench 6.3 Single-Core
384 punten (10%)
+ 1 Meer details   + Toon vergelijkingstabel
Geekbench 6.3 - Geekbench 6.3 Multi-Core
668 punten (3%)
+ 1 Meer details   - Verberg vergelijkingstabel
Intel Celeron N4500
662 -1%
Intel Pentium B970
668
Intel Pentium Gold 4425Y
763 14%
Intel Pentium Silver N6005
1332 99%
Intel Processor N200
1660 149%
Intel Processor N50
2024 203%
Qualcomm Snapdragon 7c+ Gen 3
2244 236%
Intel Core i3-N300
2803 320%
Intel Processor N100
2937 340%
Intel Processor N95
2958 343%
Intel Core i3-1005G1
3165 374%
...
Apple M3 Max 16-Core
21254 3082%
max:
AMD Ryzen Threadripper PRO 7995WX
25365 3697%
0%
100%
Geekbench 5.5 - Geekbench 5.1 - 5.5 64 Bit Single-Core
435 punten (17%)
+ 1 Meer details   - Verberg vergelijkingstabel
AMD E1-2100
125 -71%
...
AMD A10-5745M
388 -11%
AMD A8-5550M
395 -9%
Intel Celeron J4115
399 -8%
Intel Celeron N4100
403.3 -7%
Intel Celeron N4020
418.7 -4%
Intel Pentium Silver N5000
421 -3%
Intel Pentium Gold 4425Y
423 -3%
Intel Celeron N4000
433.5 0%
Intel Celeron 3867U
434 0%
Intel Pentium B970
435
Intel Celeron N4120
442 2%
AMD A10-4600M
446 3%
AMD A4-5150M
454 4%
Intel Celeron J4125
454.2 4%
AMD 3015e
464 7%
Intel Celeron 5205U
480 10%
AMD FX-7600P
487 12%
Qualcomm Snapdragon 850
488 12%
Intel Pentium Silver N5030
491.7 13%
...
Apple M3 Pro 11-Core
2331 436%
max:
AMD Ryzen 9 9900X
2544 485%
0%
100%
Geekbench 5.5 - Geekbench 5.1 - 5.5 64 Bit Multi-Core
821 punten (1%)
+ 1 Meer details   - Verberg vergelijkingstabel
AMD E1-2100
238.5 -71%
Intel Core 2 Duo SU7300
392 -52%
Intel Celeron N2820
405 -51%
Intel Celeron N3350
606 -26%
AMD A4-5150M
633 -23%
AMD A4-5000
676 -18%
Intel Atom x7-Z8750
770 -6%
Intel Celeron N4020
786 -4%
Intel Celeron N4000
802 -2%
Intel Pentium B970
821
AMD A6-5200
832 1%
Intel Celeron N6211
844 3%
AMD 3015e
860 5%
Intel Celeron 3867U
873 6%
Intel Celeron 5205U
912 11%
Intel Celeron N4500
929 13%
Intel Pentium N4200
935 14%
Intel Pentium Gold 4425Y
983 20%
AMD A10-5745M
1015 24%
...
Apple M3 Max 16-Core
22938 2694%
max:
AMD Ryzen Threadripper PRO 7995WX
55811 6698%
0%
100%
CrossMark - CrossMark Overall
231 Points (9%)
+ 1 Meer details   + Toon vergelijkingstabel
- Benchmarkresultaten voor deze videokaart
- Gemiddelde benchmarkresultaten voor deze videokaart
* Kleinere getallen betekenen een hogere prestatie

v1.28
log 08. 13:22:50

#0 ran 0s before starting gpusingle class +0s ... 0s

#1 no ids found in url (should be separated by "_") +0s ... 0s

#2 not redirecting to Ajax server +0s ... 0s

#3 did not recreate cache, as it is less than 5 days old! Created at Wed, 06 Nov 2024 07:42:07 +0100 +0.001s ... 0.001s

#4 no comparison url found in template nbc.compare_page_2 needed +0.016s ... 0.018s

#5 no comparison url found in template nbc.compare_page_2 needed +0s ... 0.018s

#6 no comparison url found in template nbc.compare_page_2 needed +0s ... 0.018s

#7 no comparison url found in template nbc.compare_page_2 needed +0s ... 0.019s

#8 no comparison url found in template nbc.compare_page_2 needed +0s ... 0.019s

#9 no comparison url found in template nbc.compare_page_2 needed +0s ... 0.019s

#10 no comparison url found in template nbc.compare_page_2 needed +0s ... 0.019s

#11 no comparison url found in template nbc.compare_page_2 needed +0s ... 0.02s

#12 no comparison url found in template nbc.compare_page_2 needed +0s ... 0.02s

#13 composed specs +0s ... 0.02s

#14 did output specs +0s ... 0.02s

#15 getting avg benchmarks for device 3017 +0.004s ... 0.024s

#16 got single benchmarks 3017 +1.93s ... 1.954s

#17 got avg benchmarks for devices +0s ... 1.954s

#18 min, max, avg, median took s +7.676s ... 9.63s

#19 no comparison url found in template nbc.compare_page_2 needed +0s ... 9.63s

#20 return log +0s ... 9.63s

Testrapporten voor de Intel Pentium B970 processor

HP 650-B6N63EA: Intel HD Graphics (Sandy Bridge), 15.60", 2.5 kg
  Extern testrapport » HP 650-B6N63EA

Samsung 350E7C-S02CZ: Intel HD Graphics (Sandy Bridge), 17.10", 2.7 kg
  Extern testrapport » Samsung 350E7C-S02CZ

Acer TravelMate 5760Z-B9704G50Mnsk: Intel Graphics Media Accelerator (GMA) HD Graphics, 15.60", 2.4 kg
  Extern testrapport » Acer TravelMate 5760Z-B9704G50Mnsk

Lenovo IdeaPad N581-MBA4YGE: Intel HD Graphics (Sandy Bridge), 15.60", 2.6 kg
  Extern testrapport » Lenovo IdeaPad N581-MBA4YGE

Toshiba Satellite C855-S5231: Intel HD Graphics 2000, 15.60", 2.4 kg
  Extern testrapport » Toshiba Satellite C855-S5231

Please share our article, every link counts!

» Mobiele CPU vergelijking
Vergelijking van alle mobiele CPU's

» Mobiele Processoren - Benchmark lijst
Benchmark lijst van alle gekende CPU's die in laptops gebruikt worden (desktop en laptop CPU's)

Andere CPU's van de serie Pentium

» Intel Pentium Gold 5405U
   2x 2.3 GHz
» Intel Pentium 4405U
   2x 2.1 GHz
» Intel Pentium 3560M
   2x 2.4 GHz
» Intel Pentium 2030M
   2x 2.5 GHz
» Intel Pentium 3550M
   2x 2.3 GHz
» Intel Pentium 2020M
   2x 2.4 GHz
» Intel Pentium 3825U
   2x 1.9 GHz
» Intel Pentium B980
   2x 2.4 GHz
» Intel Pentium 4405Y
   2x 1.5 GHz
» Intel Pentium B970
   2x 2.3 GHz
» Intel Pentium N4200
   4x 1.1 GHz - 2.5 GHz
» Intel Pentium B960
   2x 2.2 GHz
» Intel Pentium 3805U
   2x 1.9 GHz
» Intel Pentium B950
   2x 2.1 GHz
» Intel Pentium P6300
   2x 2.27 GHz
» Intel Pentium 2127U
   2x 1.9 GHz
» Intel Pentium B940
   2x 2 GHz
» Intel Pentium 3558U
   2x 1.7 GHz
» Intel Pentium 3556U
   2x 1.7 GHz
» Intel Pentium 2117U
   2x 1.8 GHz
» Intel Pentium P6200
   2x 2.13 GHz
» Intel Pentium P6100
   2x 2 GHz
» Intel Pentium N3540
   4x 2.16 GHz - 2.66 GHz
» Intel Pentium N3710
   4x 1.6 GHz - 2.56 GHz
» Intel Pentium P6000
   2x 1.86 GHz
» Intel Pentium J2900
   4x 2.41 GHz - 2.67 GHz
» Intel Pentium N3530
   4x 2.16 GHz - 2.58 GHz
» Intel Pentium N3700
   4x 1.6 GHz - 2.4 GHz
» Intel Pentium J2850
   4x 2.4 GHz
» Intel Pentium N3520
   4x 2.17 GHz - 2.42 GHz
» Intel Pentium N3510
   4x 2 GHz
» Intel Pentium 997
   2x 1.6 GHz
» Intel Pentium 987
   2x 1.5 GHz
» Intel Pentium 3561Y
   2x 1.2 GHz
» Intel Pentium 3560Y
   2x 1.2 GHz
» Intel Pentium 2129Y
   2x 1.1 GHz
» Intel Pentium 977
   2x 1.4 GHz
» Intel Pentium 967
   2x 1.3 GHz
» Intel Pentium U5600
   2x 1.33 GHz
» Intel Pentium 957
   2x 1.2 GHz
» Intel Pentium U5400
   2x 1.2 GHz
» Intel Pentium SU2700
   1x 1.3 GHz

Omringende CPU's

+ AMD Phenom II X4 N970
   4x 2.2 GHz
+ Intel Core 2 Duo SP9600
   2x 2.53 GHz
+ Intel Core 2 Duo P9500
   2x 2.53 GHz
+ Intel Core 2 Duo T9400
   2x 2.53 GHz
+ Intel Core i5-4200Y
   2x 1.4 GHz - 1.9 GHz
» Intel Pentium B970
   2x 2.3 GHz
- Intel Celeron 3765U
   2x 1.9 GHz
- Intel Pentium N4200
   4x 1.1 GHz - 2.5 GHz
- Intel Celeron 2950M
   2x 2 GHz
- AMD A8-7410
   4x 2.2 GHz - 2.5 GHz
- AMD A8-7100
   4x 1.8 GHz - 3 GHz
> Overzichten en testrapporten over laptops en mobieltjes > FAQ / Techniek > Processor voor Notebook > Intel Pentium B970 Notebook Processor
Klaus Hinum (Update: 2012-05-18)
