ATI Mobility Radeon HD 2300

ATI Mobility Radeon HD 2300

De Mobility Radeon HD 2300 grafische kaart voor laptops is de opvolger van de X1300 en ondersteunt alleen DirectX9 (volgens de informatie op de AMD homepage). De prestaties zullen iets hoger zijn dan de X1300 en daardoor zullen de huidige gaming prestaties matig tot slecht zijn. AMD / ATI schrijft dat de verhouding tussen prestaties/watt verbeterd zijn. Er wordt gezegd dat de chip slechts een hernoemde X1300 / X1350 video chip is.

Een verschil met de X2300 zijn de versterkte video opties(UVD).

De HD 2300 grafische processor is gecertificeerd voor Windows Vista en ondersteunt de Windows Aero Glass Interface.

CodenaamM71
ArchitectuurRV5xx
Pipelines4 / 2 Pixel- / Vertexshader
Core-snelheid480 MHz
Geheugensnelheid400 MHz
Geheugenbusbreedte128 bit
GeheugentypeDDR1/DDR2/GDDR3
Gedeeld geheugennee
APIDirectX 9c, Shader 3.0
Aantal Transistoren115 miljoen
technologie90 nm
Faciliteiten90nm productie proces, PCI Express X16 Interface, PowerPlay 6.0, Avivo Video architecture (MPEG-2, MPEG-4, DivX, WMV9, VC-1 acceleration), 64-bit floating point HDR, Ultra-Threaded Shader Engine, OpenGL 2.0
Aangekondigde datum01.03.2007
Link naar fabrikantati.amd.com

Benchmarks

3DMark 2001SE - 3DMark 2001 - Standard
9000 Points (9%)
+ 1 Meer details   + Toon vergelijkingstabel
3DMark 03 - 3DMark 03 - Standard
3561 Points (2%)
+ 1 Meer details   + Toon vergelijkingstabel
3DMark 05 - 3DMark 05 - Standard
1902 Points (2%)
+ 1 Meer details   - Verberg vergelijkingstabel
3DMark 06 3DMark 06 - Score Unknown Settings +
3DMark 06
896 punten (1%)
+ 1 Meer details   + Toon vergelijkingstabel
3DMark 06 - Standard 1024x768 +
3DMark 06
773 Points (1%)
+ 1 Meer details   + Toon vergelijkingstabel
- Benchmarkresultaten voor deze videokaart
- Gemiddelde benchmarkresultaten voor deze videokaart
* Kleinere getallen betekenen een hogere prestatie

Voor meer games die mogelijk speelbaar zijn of voor een lijst van alle games en videokaarten, bezoek onze Gaming List

v1.28
log 09. 07:03:45

#0 ran 0s before starting gpusingle class +0s ... 0s

#1 no ids found in url (should be separated by "_") +0s ... 0s

#2 not redirecting to Ajax server +0s ... 0s

#3 did not recreate cache, as it is less than 5 days old! Created at Fri, 08 Nov 2024 19:43:11 +0100 +0.001s ... 0.001s

#4 composed specs +0.029s ... 0.03s

#5 did output specs +0s ... 0.03s

#6 start showIntegratedCPUs +0s ... 0.03s

#7 getting avg benchmarks for device 91 +0.012s ... 0.042s

#8 got single benchmarks 91 +0.009s ... 0.051s

#9 got avg benchmarks for devices +0s ... 0.051s

#10 min, max, avg, median took s +0.124s ... 0.175s

#11 before gaming benchmark output +0s ... 0.175s

#12 Got 0 rows for game benchmarks. +0.001s ... 0.176s

#13 no comparison url found in template nbc.compare_page_1 needed +0.002s ... 0.178s

#14 return log +0s ... 0.178s

Notebook-testrapporten met ATI Mobility Radeon HD 2300 grafische kaart

Sony Vaio VGN-CR21Z: Intel Core 2 Duo T7250, 14.10", 2.5 kg
  Extern testrapport » Sony Vaio VGN-CR21Z

Sony Vaio VGN-CR11Z: Intel Core 2 Duo T7100, 14.10", 2.5 kg
  Extern testrapport » Sony Vaio VGN-CR11Z

Sony Vaio VGN-BX41VN: Intel Core 2 Duo T7300, 15.40", 3 kg
  Extern testrapport » Sony Vaio VGN-BX41VN
