De AMD Radeon RX 6500M is een mobiele grafische kaart op instapniveau, gebaseerd op de Navi 24 chip (RDNA 2 architectuur), vervaardigd in het moderne 6nm proces. De kaart beschikt over 1024 kernen (16 CU's - rekeneenheden) en 4 GB snel GDDR6 grafisch geheugen, verbonden met een 128-bits geheugenbus. De chip bevat ook 16 MB Infinity Cache. De kloksnelheid van het spel wordt gespecificeerd op 2191 MHz. AMD specificeert de theoretische prestaties op 9,97 TFLOPS (halve precisie +60% vs 6300M) en 4,98 TFLOPS (enkele precisie). De 6500M ondersteunt Smart Access Memory en SmartShift Technologie.
De prestaties zouden vergelijkbaar moeten zijn met een mobiele RTX 3050 (volgens AMD) en daarom het meest geschikt voor 1080p gaming met hoge instellingen.
De Navi 24 chip wordt gefabriceerd bij TSMC in het moderne 6nm proces en zou een goede energie-efficiëntie moeten bieden. De RX6500M wordt gespecificeerd op een TDP van 50 Watt en is daarom het meest geschikt voor normale multimedia laptops.
Radeon RX 6000M Serie
| ||||||||||||||||||||||||||||||||||||||||||||||
| Architectuur | RDNA 2 | |||||||||||||||||||||||||||||||||||||||||||||
| Pipelines | 1024 - verenigd | |||||||||||||||||||||||||||||||||||||||||||||
| TMUs | 64 | |||||||||||||||||||||||||||||||||||||||||||||
| ROPs | 32 | |||||||||||||||||||||||||||||||||||||||||||||
| Core-snelheid | 2191 (Boost) MHz | |||||||||||||||||||||||||||||||||||||||||||||
| Theoretical Performance | 9.97 TFLOPS FP16, 4.98 TFLOPS FP32 | |||||||||||||||||||||||||||||||||||||||||||||
| Cache | L3: 16 MB | |||||||||||||||||||||||||||||||||||||||||||||
| Geheugensnelheid | 18000 MHz | |||||||||||||||||||||||||||||||||||||||||||||
| Geheugenbusbreedte | 64 bit | |||||||||||||||||||||||||||||||||||||||||||||
| Geheugentype | GDDR6 | |||||||||||||||||||||||||||||||||||||||||||||
| Max. hoeveelheid geheugen | 4 GB | |||||||||||||||||||||||||||||||||||||||||||||
| Gedeeld geheugen | nee | |||||||||||||||||||||||||||||||||||||||||||||
| Memory Bandwidth | 128 GB/s | |||||||||||||||||||||||||||||||||||||||||||||
| API | DirectX 12_2, Shader 6.4, OpenGL 4.6, OpenCL 2.2, Vulkan 1.3 | |||||||||||||||||||||||||||||||||||||||||||||
| Stroomverbruik | 50 Watt | |||||||||||||||||||||||||||||||||||||||||||||
| Aantal Transistoren | 5.4 Billion | |||||||||||||||||||||||||||||||||||||||||||||
| Die Size | 107 mm² | |||||||||||||||||||||||||||||||||||||||||||||
| technologie | 6 nm | |||||||||||||||||||||||||||||||||||||||||||||
| PCIe | 4.0 x4 | |||||||||||||||||||||||||||||||||||||||||||||
| Faciliteiten | DisplayPort 1.4 w/DFSC, HDMI 2.0b, Radeon Media Engine (H.264 4K150 decode, 4K90 encode / H.265 4K90 decode, 4K60 encode / VP9 4K90 decode) | |||||||||||||||||||||||||||||||||||||||||||||
| Laptop Grootte | gemiddeld formaat | |||||||||||||||||||||||||||||||||||||||||||||
| Aangekondigde datum | 04.01.2022 | |||||||||||||||||||||||||||||||||||||||||||||
| Link naar fabrikant | www.amd.com | |||||||||||||||||||||||||||||||||||||||||||||
| Model | CPU | GPU | RAM | waarde |
|---|---|---|---|---|
| HP Victus 15-fb0354ng | R5 5600H 100 W / 94 W | Radeon RX 6500M 2433 / 2000 MHz 4 GB | 8 GB | 4527 |
| Lenovo ThinkPad Z16 G1 21D5S00T00 | R7 PRO 6850H 65 W / 47 W | Radeon RX 6500M 55 W 2433 / 2000 MHz 4 GB | 32 GB | 4795 |
| GPU TDP ? | TDP 55 W |
|---|---|
| 94% | 100% |
| Model | CPU | GPU | RAM | waarde |
|---|---|---|---|---|
| HP Victus 15-fb0354ng | R5 5600H 100 W / 94 W | Radeon RX 6500M 2433 / 2000 MHz 4 GB | 8 GB | 4310 |
| Lenovo ThinkPad Z16 G1 21D5S00T00 | R7 PRO 6850H 65 W / 47 W | Radeon RX 6500M 55 W 2433 / 2000 MHz 4 GB | 32 GB | 4434 |
| GPU TDP ? | TDP 55 W |
|---|---|
| 97% | 100% |
| Model | CPU | GPU | RAM | waarde |
|---|---|---|---|---|
| HP Victus 15-fb0354ng | R5 5600H 100 W / 94 W | Radeon RX 6500M 2433 / 2000 MHz 4 GB | 8 GB | 33249 |
| Lenovo ThinkPad Z16 G1 21D5S00T00 | R7 PRO 6850H 65 W / 47 W | Radeon RX 6500M 55 W 2433 / 2000 MHz 4 GB | 32 GB | 92553 |
| GPU TDP ? | TDP 55 W |
|---|---|
| 36% | 100% |
| Model | CPU | GPU | RAM | waarde |
|---|---|---|---|---|
| HP Victus 15-fb0354ng | R5 5600H 100 W / 94 W | Radeon RX 6500M 2433 / 2000 MHz 4 GB | 8 GB | 84648 |
| Lenovo ThinkPad Z16 G1 21D5S00T00 | R7 PRO 6850H 65 W / 47 W | Radeon RX 6500M 55 W 2433 / 2000 MHz 4 GB | 32 GB | 92553 |
| GPU TDP ? | TDP 55 W |
|---|---|
| 91% | 100% |
| Model | CPU | GPU | RAM | waarde |
|---|---|---|---|---|
| HP Victus 15-fb0354ng | R5 5600H 100 W / 94 W | Radeon RX 6500M 2433 / 2000 MHz 4 GB | 8 GB | 12006 |
| Lenovo ThinkPad Z16 G1 21D5S00T00 | R7 PRO 6850H 65 W / 47 W | Radeon RX 6500M 55 W 2433 / 2000 MHz 4 GB | 32 GB | 12287 |
| GPU TDP ? | TDP 55 W |
|---|---|
| 98% | 100% |
| Model | CPU | GPU | RAM | waarde |
|---|---|---|---|---|
| Lenovo ThinkPad Z16 G1 21D5S00T00 | R7 PRO 6850H 65 W / 47 W | Radeon RX 6500M 55 W 2433 / 2000 MHz 4 GB | 32 GB | 13980 |
| HP Victus 15-fb0354ng | R5 5600H 100 W / 94 W | Radeon RX 6500M 2433 / 2000 MHz 4 GB | 8 GB | 14055 |
| GPU TDP ? | TDP 55 W |
|---|---|
| 100% | 99% |
| Model | CPU | GPU | RAM | waarde |
|---|---|---|---|---|
| HP Victus 15-fb0354ng | R5 5600H 100 W / 94 W | Radeon RX 6500M 2433 / 2000 MHz 4 GB | 8 GB | 28957 |
| Model | CPU | GPU | RAM | waarde |
|---|---|---|---|---|
| HP Victus 15-fb0354ng | R5 5600H 100 W / 94 W | Radeon RX 6500M 2433 / 2000 MHz 4 GB | 8 GB | 8144 |
| Model | CPU | GPU | RAM | waarde |
|---|---|---|---|---|
| HP Victus 15-fb0354ng | R5 5600H 100 W / 94 W | Radeon RX 6500M 2433 / 2000 MHz 4 GB | 8 GB | 14906 |
| Lenovo ThinkPad Z16 G1 21D5S00T00 | R7 PRO 6850H 65 W / 47 W | Radeon RX 6500M 55 W 2433 / 2000 MHz 4 GB | 32 GB | 17548 |
| GPU TDP ? | TDP 55 W |
|---|---|
| 85% | 100% |
| Model | CPU | GPU | RAM | waarde |
|---|---|---|---|---|
| Lenovo ThinkPad Z16 G1 21D5S00T00 | R7 PRO 6850H 65 W / 47 W | Radeon RX 6500M 55 W 2433 / 2000 MHz 4 GB | 32 GB | 16290 |
| HP Victus 15-fb0354ng | R5 5600H 100 W / 94 W | Radeon RX 6500M 2433 / 2000 MHz 4 GB | 8 GB | 19488 |
| GPU TDP ? | TDP 55 W |
|---|---|
| 100% | 84% |
| Model | CPU | GPU | RAM | waarde |
|---|---|---|---|---|
| Lenovo ThinkPad Z16 G1 21D5S00T00 | R7 PRO 6850H 65 W / 47 W | Radeon RX 6500M 55 W 2433 / 2000 MHz 4 GB | 32 GB | 51599 |
| HP Victus 15-fb0354ng | R5 5600H 100 W / 94 W | Radeon RX 6500M 2433 / 2000 MHz 4 GB | 8 GB | 52723 |
| GPU TDP ? | TDP 55 W |
|---|---|
| 100% | 98% |
| Model | CPU | GPU | RAM | waarde |
|---|---|---|---|---|
| HP Victus 15-fb0354ng | R5 5600H 100 W / 94 W | Radeon RX 6500M 2433 / 2000 MHz 4 GB | 8 GB | 52733 |
| Model | CPU | GPU | RAM | waarde | |
|---|---|---|---|---|---|
| 3DMark 06 - Standard 1280x1024 | |||||
| HP Victus 15-fb0354ng (3DMark 06 - Standard 1280x1024) | R5 5600H 100 W / 94 W | Radeon RX 6500M 2433 / 2000 MHz 4 GB | 8 GB | 23954 | |
| Lenovo ThinkPad Z16 G1 21D5S00T00 (3DMark 06 - Standard 1280x1024) | R7 PRO 6850H 65 W / 47 W | Radeon RX 6500M 55 W 2433 / 2000 MHz 4 GB | 32 GB | 35958 | |
| GPU TDP ? | TDP 55 W |
|---|---|
| 67% | 100% |
| Model | CPU | GPU | RAM | waarde |
|---|---|---|---|---|
| Lenovo ThinkPad Z16 G1 21D5S00T00 | R7 PRO 6850H 65 W / 47 W | Radeon RX 6500M 55 W 2433 / 2000 MHz 4 GB | 32 GB | 110 |
| HP Victus 15-fb0354ng | R5 5600H 100 W / 94 W | Radeon RX 6500M 2433 / 2000 MHz 4 GB 3.3.3 | 8 GB | 129 |
| GPU TDP ? | TDP 55 W |
|---|---|
| 100% | 102% |
| Model | CPU | GPU | RAM | waarde |
|---|---|---|---|---|
| HP Victus 15-fb0354ng | R5 5600H 100 W / 94 W | Radeon RX 6500M 2433 / 2000 MHz 4 GB | 8 GB | 12202 |
| Lenovo ThinkPad Z16 G1 21D5S00T00 | R7 PRO 6850H 65 W / 47 W | Radeon RX 6500M 55 W 2433 / 2000 MHz 4 GB | 32 GB | 13701 |
| GPU TDP ? | TDP 55 W |
|---|---|
| 89% | 100% |
| Model | CPU | GPU | RAM | waarde |
|---|---|---|---|---|
| Lenovo ThinkPad Z16 G1 21D5S00T00 | R7 PRO 6850H 65 W / 47 W | Radeon RX 6500M 55 W 2433 / 2000 MHz 4 GB | 32 GB | 144.15 |
| Model | CPU | GPU | RAM | waarde |
|---|---|---|---|---|
| HP Victus 15-fb0354ng | R5 5600H 100 W / 94 W | Radeon RX 6500M 2433 / 2000 MHz 4 GB | 8 GB | 162.6 |
| Lenovo ThinkPad Z16 G1 21D5S00T00 | R7 PRO 6850H 65 W / 47 W | Radeon RX 6500M 55 W 2433 / 2000 MHz 4 GB | 32 GB | 181 |
| GPU TDP ? | TDP 55 W |
|---|---|
| 90% | 100% |
| Model | CPU | GPU | RAM | waarde |
|---|---|---|---|---|
| HP Victus 15-fb0354ng | R5 5600H 100 W / 94 W | Radeon RX 6500M 2433 / 2000 MHz 4 GB | 8 GB | 97.9 |
| Lenovo ThinkPad Z16 G1 21D5S00T00 | R7 PRO 6850H 65 W / 47 W | Radeon RX 6500M 55 W 2433 / 2000 MHz 4 GB | 32 GB | 98 |
| GPU TDP ? | TDP 55 W |
|---|---|
| 100% | 100% |
| Model | CPU | GPU | RAM | waarde |
|---|---|---|---|---|
| HP Victus 15-fb0354ng | R5 5600H 100 W / 94 W | Radeon RX 6500M 2433 / 2000 MHz 4 GB Vulkan | 8 GB | 47.1 |
| Model | CPU | GPU | RAM | waarde |
|---|---|---|---|---|
| HP Victus 15-fb0354ng | R5 5600H 100 W / 94 W | Radeon RX 6500M 2433 / 2000 MHz 4 GB | 8 GB | 109 |
| Model | CPU | GPU | RAM | waarde |
|---|---|---|---|---|
| HP Victus 15-fb0354ng | R5 5600H 100 W / 94 W | Radeon RX 6500M 2433 / 2000 MHz 4 GB Vulkan | 8 GB | 309.6 |
| Model | CPU | GPU | RAM | waarde |
|---|---|---|---|---|
| HP Victus 15-fb0354ng | R5 5600H 100 W / 94 W | Radeon RX 6500M 2433 / 2000 MHz 4 GB | 8 GB | 302.5 |
| Model | CPU | GPU | RAM | waarde |
|---|---|---|---|---|
| HP Victus 15-fb0354ng | R5 5600H 100 W / 94 W | Radeon RX 6500M 2433 / 2000 MHz 4 GB | 8 GB | 415.6 |
| Model | CPU | GPU | RAM | waarde |
|---|---|---|---|---|
| HP Victus 15-fb0354ng | R5 5600H 100 W / 94 W | Radeon RX 6500M 2433 / 2000 MHz 4 GB | 8 GB | 553.2 |
| Model | CPU | GPU | RAM | waarde |
|---|---|---|---|---|
| HP Victus 15-fb0354ng | R5 5600H 100 W / 94 W | Radeon RX 6500M 2433 / 2000 MHz 4 GB | 8 GB | 1062.5 |
| Model | CPU | GPU | RAM | waarde |
|---|---|---|---|---|
| HP Victus 15-fb0354ng | R5 5600H 100 W / 94 W | Radeon RX 6500M 2433 / 2000 MHz 4 GB 6.2.1 | 8 GB | 42333 |
| Model | CPU | GPU | RAM | waarde |
|---|---|---|---|---|
| HP Victus 15-fb0354ng | R5 5600H 100 W / 94 W | Radeon RX 6500M 2433 / 2000 MHz 4 GB 6.2.1 | 8 GB | 49243 |
| Model | CPU | GPU | RAM | waarde |
|---|---|---|---|---|
| HP Victus 15-fb0354ng | R5 5600H 100 W / 94 W | Radeon RX 6500M 2433 / 2000 MHz 4 GB | 8 GB | 1037 |
| Lenovo ThinkPad Z16 G1 21D5S00T00 | R7 PRO 6850H 65 W / 47 W | Radeon RX 6500M 55 W 2433 / 2000 MHz 4 GB | 32 GB | 1094 |
| GPU TDP ? | TDP 55 W |
|---|---|
| 95% | 100% |
| Model | CPU | GPU | RAM | waarde |
|---|---|---|---|---|
| Lenovo ThinkPad Z16 G1 21D5S00T00 | R7 PRO 6850H 65 W / 47 W | Radeon RX 6500M 55 W 2433 / 2000 MHz 4 GB | 32 GB | 1717 |
| HP Victus 15-fb0354ng | R5 5600H 100 W / 94 W | Radeon RX 6500M 2433 / 2000 MHz 4 GB | 8 GB | 2390 |
| GPU TDP ? | TDP 55 W |
|---|---|
| 100% | 72% |
| Model | CPU | GPU | RAM | waarde |
|---|---|---|---|---|
| Lenovo ThinkPad Z16 G1 21D5S00T00 | R7 PRO 6850H 65 W / 47 W | Radeon RX 6500M 55 W 2433 / 2000 MHz 4 GB | 32 GB | 8384 |
| HP Victus 15-fb0354ng | R5 5600H 100 W / 94 W | Radeon RX 6500M 2433 / 2000 MHz 4 GB | 8 GB | 8991 |
| GPU TDP ? | TDP 55 W |
|---|---|
| 100% | 93% |
| Model | CPU | GPU | RAM | waarde |
|---|---|---|---|---|
| Lenovo ThinkPad Z16 G1 21D5S00T00 | R7 PRO 6850H 65 W / 47 W | Radeon RX 6500M 55 W 2433 / 2000 MHz 4 GB | 32 GB | 102.4 |
| Model | CPU | GPU | RAM | waarde |
|---|---|---|---|---|
| Lenovo ThinkPad Z16 G1 21D5S00T00 | R7 PRO 6850H 65 W / 47 W | Radeon RX 6500M 55 W 2433 / 2000 MHz 4 GB | 32 GB | 104.7 |
| Model | CPU | GPU | RAM | waarde |
|---|---|---|---|---|
| Lenovo ThinkPad Z16 G1 21D5S00T00 | R7 PRO 6850H 65 W / 47 W | Radeon RX 6500M 55 W 2433 / 2000 MHz 4 GB | 32 GB | 93.6 |
| Model | CPU | GPU | RAM | waarde |
|---|---|---|---|---|
| Lenovo ThinkPad Z16 G1 21D5S00T00 | R7 PRO 6850H 65 W / 47 W | Radeon RX 6500M 55 W 2433 / 2000 MHz 4 GB | 32 GB | 0.4177 |
| Model | CPU | GPU | RAM | waarde |
|---|---|---|---|---|
| Lenovo ThinkPad Z16 G1 21D5S00T00 | R7 PRO 6850H 65 W / 47 W | Radeon RX 6500M 55 W 2433 / 2000 MHz 4 GB | 32 GB | 0.3734 |
| Model | CPU | GPU | RAM | waarde |
|---|---|---|---|---|
| Lenovo ThinkPad Z16 G1 21D5S00T00 | R7 PRO 6850H 65 W / 47 W | Radeon RX 6500M 55 W 2433 / 2000 MHz 4 GB | 32 GB | 46.9 |
- Gemiddelde benchmarkresultaten voor deze videokaartDe volgende benchmarks zijn afgeleid van onze laptop-testrapporten. De prestaties variëren afhankelijk van het gebruikte grafische geheugen, kloksnelheid, processor, systeeminstellingen, drivers en besturingssysteem. De resultaten zijn daarom niet noodzakelijk representatief voor alle laptops met deze GPU. Voor meer gedetailleerde informatie over de benchmarkresultaten, klik op het fps-aantal.
Voor meer games die mogelijk speelbaar zijn of voor een lijst van alle games en videokaarten, bezoek onze Gaming List
#0 ran 0s before starting gpusingle class +0s ... 0s
#1 no ids found in url (should be separated by "_") +0s ... 0s
#2 not redirecting to Ajax server +0s ... 0s
#3 did not recreate cache, as it is less than 5 days old! Created at Tue, 19 Nov 2024 05:32:27 +0100 +0.001s ... 0.001s
#4 no comparison url found in template nbc.compare_page_1 needed +0.024s ... 0.025s
#5 no comparison url found in template nbc.compare_page_1 needed +0s ... 0.025s
#6 no comparison url found in template nbc.compare_page_1 needed +0s ... 0.025s
#7 no comparison url found in template nbc.compare_page_1 needed +0s ... 0.026s
#8 no comparison url found in template nbc.compare_page_1 needed +0s ... 0.026s
#9 no comparison url found in template nbc.compare_page_1 needed +0s ... 0.026s
#10 no comparison url found in template nbc.compare_page_1 needed +0s ... 0.026s
#11 no comparison url found in template nbc.compare_page_1 needed +0s ... 0.027s
#12 no comparison url found in template nbc.compare_page_1 needed +0s ... 0.027s
#13 no comparison url found in template nbc.compare_page_1 needed +0s ... 0.027s
#14 no comparison url found in template nbc.compare_page_1 needed +0s ... 0.027s
#15 no comparison url found in template nbc.compare_page_1 needed +0s ... 0.027s
#16 no comparison url found in template nbc.compare_page_1 needed +0s ... 0.028s
#17 no comparison url found in template nbc.compare_page_1 needed +0s ... 0.028s
#18 composed specs +0s ... 0.028s
#19 did output specs +0s ... 0.028s
#20 start showIntegratedCPUs +0s ... 0.028s
#21 getting avg benchmarks for device 11130 +0.013s ... 0.041s
#22 got single benchmarks 11130 +0.016s ... 0.057s
#23 got avg benchmarks for devices +0s ... 0.057s
#24 min, max, avg, median took s +0.63s ... 0.687s
#25 before gaming benchmark output +0s ... 0.687s
#26 Got 250 rows for game benchmarks. +0.039s ... 0.726s
#27 composed SQL query for gamebenchmarks +0s ... 0.726s
#28 got data and put it in $dataArray +0.037s ... 0.763s
#29 benchmarks composed for output. +2.102s ... 2.865s
#30 no comparison url found in template nbc.compare_page_1 needed +0.006s ... 2.871s
#31 return log +0s ... 2.871s
MSI Bravo 15 B5ED, R7 5800H: AMD Ryzen 7 5800H, 15.60", 2.4 kg
Extern testrapport » MSI Bravo 15 B5ED, R7 5800H
Lenovo ThinkPad Z16, R5 PRO 6650H: AMD Ryzen 5 PRO 6650H, 16.00", 1.8 kg
Extern testrapport » Lenovo ThinkPad Z16, R5 PRO 6650H
HP Victus 15-fb0035ns: AMD Ryzen 5 5600H, 15.60", 2.3 kg
Extern testrapport » HP Victus 15-fb0035ns
MSI Bravo 15 B5ED: AMD Ryzen 5 5600H, 15.60", 2.4 kg
Extern testrapport » MSI Bravo 15 B5ED
Lenovo ThinkPad Z16 G1 21D4002GG: AMD Ryzen 9 PRO 6950H, 16.00", 1.9 kg
Extern testrapport » Lenovo ThinkPad Z16 G1 21D4002GG
Lenovo ThinkPad Z16 G1 21D5S00T00: AMD Ryzen 7 PRO 6850H, 16.00", 1.9 kg
Extern testrapport » Lenovo ThinkPad Z16 G1 21D5S00T00
HP Victus 15-fb0011AX: AMD Ryzen 5 5600H, 15.60", 2.3 kg
Extern testrapport » HP Victus 15-fb0011AX
* Benaderende positie van de videokaart
» Top 10 Multimedia Notebooks
» Top 10 Gaming-Notebooks
» Top 10 Budget Gaming Laptops
» Top 10 Lichtgewicht Gaming-Notebooks
» Top 10 Premium Office/Business-Notebooks
» Top 10 Budget Office/Business-Notebooks
» Top 10 Workstation-Laptops
» Top 10 Subnotebooks
» Top 10 Ultrabooks
» Top 10 Notebooks tot €300
» Top 10 Notebooks tot €500
» Top 10 Notebooks tot € 1.000De beste notebookbeeldschermen zoals getest door Notebookcheck
» De beste notebookbeeldschermen
» Top Windows Alternatieven voor de MacBook Pro 13
» Top Windows Alternatieven voor de MacBook Pro 15
» Top Windows alternatieven voor de MacBook 12 en Air
» Top 10 best verkopende notebooks op Amazon
» Top 10 Convertible Notebooks
» Top 10 Tablets
» Top 10 Tablets tot € 250
» Top 10 Smartphones
» Top 10 Phablets (>90cm²)
» Top 10 Camera Smartphones
» Top 10 Smartphones tot €500
» Top 10 best verkopende smartphones op Amazon
