AMD Radeon HD 7660G

De AMD Radeon HD 7660G of HD7660G is een processor grafische kaart in de Trinity APU's from AMD. Het is de snelste versie en is alleen in de A10 serie te vinden. Hij is gebaseerd op de VLIW4 architectuur van de Radeon HD 6900 desktop serie en beschikt niet over dedicated grafisch geheugen.
De naam Trinity is afgeleid van het feit dat de grafische kaart uit onderdelen van drie verschillende architecturen bestaat. De CPU cores zijn gebaseerd op de Piledriver architectuur (Bulldozer opvolger), de GPU cores op de Northern Islands (6900 desktop serie architectuur) en de video processing engine en multi-display connectiviteit komen van de nieuwe Southern Island GPU architectuur (HD 7900 serie).
De geïntegreerde UVD3 video decoder (Avivo HD) ondersteunt decoding van MPEG-4 AVC/H.264, VC-1, MPEG-2, Multi-View Codec (MVC), MPEG-4 part 2 (DivX, xVid) en Adobe Flash HD video's.
De prestaties van de de Radeon HD 7660G hangen af van de gebruikte benchmark. In synthetische benchmarks als 3DMark 11 presteert hij ongeveer hetzelfde als een dedicated Radeon HD 7670M. In games (met speelbare instellingen) zijn de prestaties echter meer vergelijkbaar met die van de dedicated AMD Radeon HD 6630M. Daarom is de grafische kaart een stuk krachtiger dan de Intel HD Graphics 4000 in de Ivy Bridge quad-core modellen.
De shaders van de chip kunnen ook worden ingezet voor algemeen rekenwerk. Meer informatie en benchmarkresultaten van OpenCL en DirectCompute 11 tests zijn terug te vinden onze Trinity Test van de A10-4600M.
De APU wordt nog gemaakt op 32nm formaat en met een TDP van 35 Watt (zoals de meeste A10 serie onderdelen) is de HD 7660G het meest geschikt voor 13 tot 14 inch en grotere notebooks.
Radeon HD 7000G Serie
| |||||||||||||||||||||||||
Codenaam | Trinity | ||||||||||||||||||||||||
Architectuur | Terascale 3 | ||||||||||||||||||||||||
Pipelines | 384 - verenigd | ||||||||||||||||||||||||
Core-snelheid | 497 - 686 (Boost) MHz | ||||||||||||||||||||||||
Gedeeld geheugen | ja | ||||||||||||||||||||||||
API | DirectX 11, Shader 5.0, OpenGL 4.2 | ||||||||||||||||||||||||
Aantal Transistoren | 1.3 miljoen | ||||||||||||||||||||||||
technologie | 32 nm | ||||||||||||||||||||||||
Laptop Grootte | gemiddeld formaat | ||||||||||||||||||||||||
Aangekondigde datum | 15.05.2012 | ||||||||||||||||||||||||
Informatie | 24 TMUs, 68 ROPs, 6 Compute Units (OpenCL 1.2) |
|
Benchmarks
Model | CPU | GPU | RAM | waarde |
---|---|---|---|---|
Pumori Test Platform | A10-4600M | Radeon HD 7660G | 4 GB | 65558 |
Model | CPU | GPU | RAM | waarde |
---|---|---|---|---|
Pumori Test Platform | A10-4600M | Radeon HD 7660G | 4 GB | 45460 |
Model | CPU | GPU | RAM | waarde |
---|---|---|---|---|
Pumori Test Platform | A10-4600M | Radeon HD 7660G | 4 GB | 4106 |
AMD Pumori Platform A10-4600M | A10-4600M | Radeon HD 7660G | 4 GB | 4274 |
Model | CPU | GPU | RAM | waarde |
---|---|---|---|---|
Pumori Test Platform | A10-4600M | Radeon HD 7660G | 4 GB | 6200 |
AMD Pumori Platform A10-4600M | A10-4600M | Radeon HD 7660G | 4 GB | 6617 |
Model | CPU | GPU | RAM | waarde |
---|---|---|---|---|
AMD Pumori Platform A10-4600M | A10-4600M | Radeon HD 7660G | 4 GB | 61503 |
Pumori Test Platform | A10-4600M | Radeon HD 7660G | 4 GB | 64788 |
Model | CPU | GPU | RAM | waarde |
---|---|---|---|---|
![]() | A10-4600M | Radeon HD 7660G 685 MHz | 1135 | |
Toshiba Satellite S855D-S5256 | A10-4600M | Radeon HD 7660G 686 / 384 MHz 0.5 GB | 6 GB | 1147 |
AMD Pumori Platform A10-4600M | A10-4600M | Radeon HD 7660G | 4 GB | 1150 |
Model | CPU | GPU | RAM | waarde |
---|---|---|---|---|
AMD Pumori Platform A10-4600M | A10-4600M | Radeon HD 7660G | 4 GB | 1056 |
Toshiba Satellite S855D-S5256 | A10-4600M | Radeon HD 7660G 686 / 384 MHz 0.5 GB | 6 GB | 1058 |
3DM Vant. Perf. total +
Model | CPU | GPU | RAM | waarde |
---|---|---|---|---|
Toshiba Satellite S855D-S5256 | A10-4600M | Radeon HD 7660G 686 / 384 MHz 0.5 GB | 6 GB | 4476 |
AMD Pumori Platform A10-4600M | A10-4600M | Radeon HD 7660G | 4 GB | 4570 |
Model | CPU | GPU | RAM | waarde |
---|---|---|---|---|
Toshiba Satellite S855D-S5256 | A10-4600M | Radeon HD 7660G 686 / 384 MHz 0.5 GB | 6 GB | 4090 |
AMD Pumori Platform A10-4600M | A10-4600M | Radeon HD 7660G | 4 GB | 4176 |
Model | CPU | GPU | RAM | waarde |
---|---|---|---|---|
AMD Pumori Platform A10-4600M | A10-4600M | Radeon HD 7660G | 4 GB | 22817 |
Model | CPU | GPU | RAM | waarde |
---|---|---|---|---|
Toshiba Satellite S855D-S5256 | A10-4600M | Radeon HD 7660G 686 / 384 MHz 0.5 GB | 6 GB | 20650 |
AMD Pumori Platform A10-4600M | A10-4600M | Radeon HD 7660G | 4 GB | 21606 |
Model | CPU | GPU | RAM | waarde |
---|---|---|---|---|
Toshiba Satellite S855D-S5256 | A10-4600M | Radeon HD 7660G 686 / 384 MHz 0.5 GB | 6 GB | 9865 |
AMD Pumori Platform A10-4600M | A10-4600M | Radeon HD 7660G | 4 GB | 11235 |
Model | CPU | GPU | RAM | waarde | |
---|---|---|---|---|---|
3DMark 06 - Standard 1280x1024 | |||||
AMD Pumori Platform A10-4600M (3DMark 06 - Standard 1280x1024) | A10-4600M | Radeon HD 7660G | 4 GB | 7316 | |
Toshiba Satellite S855D-S5256 (3DMark 06 - Standard 1280x1024) | A10-4600M | Radeon HD 7660G 686 / 384 MHz 0.5 GB | 6 GB | 7318 |
Model | CPU | GPU | RAM | waarde |
---|---|---|---|---|
AMD Pumori Platform A10-4600M | A10-4600M | Radeon HD 7660G | 4 GB | 4.5 |
Model | CPU | GPU | RAM | waarde |
---|---|---|---|---|
Toshiba Satellite S855D-S5256 | A10-4600M | Radeon HD 7660G 686 / 384 MHz 0.5 GB | 6 GB | 9.6 |
AMD Pumori Platform A10-4600M | A10-4600M | Radeon HD 7660G | 4 GB | 15 |
specvp11 snx-01 +
Model | CPU | GPU | RAM | waarde |
---|---|---|---|---|
AMD Pumori Platform A10-4600M | A10-4600M | Radeon HD 7660G | 4 GB | 6.26 |
Model | CPU | GPU | RAM | waarde |
---|---|---|---|---|
AMD Pumori Platform A10-4600M | A10-4600M | Radeon HD 7660G | 4 GB | 3.02 |
Model | CPU | GPU | RAM | waarde |
---|---|---|---|---|
AMD Pumori Platform A10-4600M | A10-4600M | Radeon HD 7660G | 4 GB | 12.06 |
Model | CPU | GPU | RAM | waarde |
---|---|---|---|---|
AMD Pumori Platform A10-4600M | A10-4600M | Radeon HD 7660G | 4 GB | 1.14 |
Model | CPU | GPU | RAM | waarde |
---|---|---|---|---|
AMD Pumori Platform A10-4600M | A10-4600M | Radeon HD 7660G | 4 GB | 6.86 |
Model | CPU | GPU | RAM | waarde |
---|---|---|---|---|
AMD Pumori Platform A10-4600M | A10-4600M | Radeon HD 7660G | 4 GB | 15.03 |
Model | CPU | GPU | RAM | waarde |
---|---|---|---|---|
AMD Pumori Platform A10-4600M | A10-4600M | Radeon HD 7660G | 4 GB | 15.24 |
Model | CPU | GPU | RAM | waarde |
---|---|---|---|---|
AMD Pumori Platform A10-4600M | A10-4600M | Radeon HD 7660G | 4 GB | 3.59 |
Model | CPU | GPU | RAM | waarde |
---|---|---|---|---|
AMD Pumori Platform A10-4600M | A10-4600M | Radeon HD 7660G | 4 GB | 6.7 |
Toshiba Satellite S855D-S5256 | A10-4600M | Radeon HD 7660G 686 / 384 MHz 0.5 GB | 6 GB | 6.7 |
Model | CPU | GPU | RAM | waarde |
---|---|---|---|---|
AMD Pumori Platform A10-4600M | A10-4600M | Radeon HD 7660G | 4 GB | 6.7 |
Toshiba Satellite S855D-S5256 | A10-4600M | Radeon HD 7660G 686 / 384 MHz 0.5 GB | 6 GB | 6.7 |
Model | CPU | GPU | RAM | waarde |
---|---|---|---|---|
Toshiba Satellite S855D-S5256 | A10-4600M | Radeon HD 7660G 686 / 384 MHz 0.5 GB | 6 GB | 5510 |
AMD Pumori Platform A10-4600M | A10-4600M | Radeon HD 7660G | 4 GB | 5643 |
Model | CPU | GPU | RAM | waarde |
---|---|---|---|---|
Pumori Test Platform | A10-4600M | Radeon HD 7660G | 4 GB | 29.5 |
AMD Pumori Platform A10-4600M | A10-4600M | Radeon HD 7660G | 4 GB | 29.91 |
Toshiba Satellite S855D-S5256 | A10-4600M | Radeon HD 7660G 686 / 384 MHz 0.5 GB | 6 GB | 31.2 |
Cinebench R15 OpenGL 64 Bit +
Model | CPU | GPU | RAM | waarde |
---|---|---|---|---|
AMD Pumori Platform A10-4600M | A10-4600M | Radeon HD 7660G | 4 GB | 23.8 |
AMD Pumori Platform A10-4600M | A10-4600M | Radeon HD 7660G | 4 GB | 28.7 |
Pumori Test Platform | A10-4600M | Radeon HD 7660G | 4 GB | 31.9 |
AMD Pumori Platform A10-4600M | A10-4600M | Radeon HD 7660G | 4 GB | 32.54 |
Model | CPU | GPU | RAM | waarde |
---|---|---|---|---|
AMD Pumori Platform A10-4600M | A10-4600M | Radeon HD 7660G | 4 GB | 98 |
AMD Pumori Platform A10-4600M | A10-4600M | Radeon HD 7660G | 4 GB | 98 |
AMD Pumori Platform A10-4600M | A10-4600M | Radeon HD 7660G | 4 GB | 98 |
Pumori Test Platform | A10-4600M | Radeon HD 7660G | 4 GB | 98 |
GFXBench T-Rex HD Offscreen C24Z16 +
Model | CPU | GPU | RAM | waarde |
---|---|---|---|---|
Pumori Test Platform | A10-4600M | Radeon HD 7660G | 4 GB | 93 |
Model | CPU | GPU | RAM | waarde |
---|---|---|---|---|
AMD Pumori Platform A10-4600M | A10-4600M | Radeon HD 7660G | 4 GB | 77 |
Model | CPU | GPU | RAM | waarde |
---|---|---|---|---|
AMD Pumori Platform A10-4600M | A10-4600M | Radeon HD 7660G | 4 GB | 179 |
Model | CPU | GPU | RAM | waarde |
---|---|---|---|---|
AMD Pumori Platform A10-4600M | A10-4600M | Radeon HD 7660G | 4 GB | 771 |

* Kleinere getallen betekenen een hogere prestatie
Game Benchmarks
De volgende benchmarks zijn afgeleid van onze laptop-testrapporten. De prestaties variëren afhankelijk van het gebruikte grafische geheugen, kloksnelheid, processor, systeeminstellingen, drivers en besturingssysteem. De resultaten zijn daarom niet noodzakelijk representatief voor alle laptops met deze GPU. Voor meer gedetailleerde informatie over de benchmarkresultaten, klik op het fps-aantal.

X-Plane 11.11
2018
Team Fortress 2
2017
Dirt 4
2017
Rocket League
2017
Metal Gear Solid V
2015
Mad Max
2015
Dota 2 Reborn
2015
The Witcher 3
2015
Dirt Rally
2015
Alien: Isolation
2014
Fifa 15
2014AMD A10-4600M 2.3GHz
Radeon HD 7660G
Probleem tijdens benchmarking opgetreden: stuttering

Risen 3: Titan Lords
2014
GRID: Autosport
2014
Watch Dogs
2014
Titanfall
2014
Thief
2014
X-Plane 10.25
2013
Call of Duty: Ghosts
2013
Battlefield 4
2013AMD A10-4600M 2.3GHz
Radeon HD 7660G
Probleem tijdens benchmarking opgetreden: kleine grafische problemen
min: 6 fps, max: 18 fps
AMD A10-4600M 2.3GHz
Radeon HD 7660G
Probleem tijdens benchmarking opgetreden: kleine grafische problemen
min: 4 fps, max: 7 fps

F1 2013
2013
Fifa 14
2013
Total War: Rome II
2013
Saints Row IV
2013
Company of Heroes 2
2013
Metro: Last Light
2013
BioShock Infinite
2013
SimCity
2013
Tomb Raider
2013
Crysis 3
2013
Dead Space 3
2013
Far Cry 3
2012
Assassin´s Creed III
2012
Hitman: Absolution
2012
Dishonored
2012
World of Tanks v8
2012
Fifa 13
2012
F1 2012
2012
Borderlands 2
2012
Guild Wars 2
2012
Counter-Strike: GO
2012
Darksiders II
2012
Sleeping Dogs
2012
The Secret World
2012
Max Payne 3
2012
Dirt Showdown
2012
Diablo III
2012
Risen 2: Dark Waters
2012
Mass Effect 3
2012
Alan Wake
2012
Anno 2070
2011
Battlefield 3
2011
Batman: Arkham City
2011
Fifa 12
2011
F1 2011
2011
Dirt 3
2011
Crysis 2
2011
Mafia 2
2010
StarCraft 2
2010
Metro 2033
2010Voor meer games die mogelijk speelbaar zijn of voor een lijst van alle games en videokaarten, bezoek onze Gaming List
